Ref. RPMS64N16-100LR
BUTTERFLY VALVE TAPPED ALUMINIUM BRONZE NBR BARE SHAFT DN100/PN16 3.2 LR
- Size : DN100 - 4"
- Connection : Lug
- Brand : RPM
- Material : Aluminium bronze
- Pressure : PN16
- Seal : NBR
- Thread : Female
€887.50 excl. VAT
€1,065.00 incl. VAT · list price
On order
- Minimum quantity
- 1
Log in to see your price and order, or create a company account.
Description (in French)
100MM PN16 LUG TYPE BFV NCI/BRZ/NBR - Lug Type
Butterfly Valve with Bare shaft. Body: Nodular Cast Iron
(GGG40), Disc: alubronze (AB2). Seat: NBR. Max working
pressure: 16 bar. Flange Connection: PN10/16. Face to face:
52mm
Butterfly Valve with Bare shaft. Body: Nodular Cast Iron
(GGG40), Disc: alubronze (AB2). Seat: NBR. Max working
pressure: 16 bar. Flange Connection: PN10/16. Face to face:
52mm
RPMS64N16 variants (3)
| Ref. | Description | Size | Certificate | Stock | Price excl. VAT |
|---|---|---|---|---|---|
| RPMS64N16-80 | BUTTERFLY VALVE TAPPED ALUMINIUM BRONZE NBR BARE SHAFT DN80/PN16 | DN80 - 3" | 3.1 | On order |
€215.00 |
| RPMS64N16-100LR | BUTTERFLY VALVE TAPPED ALUMINIUM BRONZE NBR BARE SHAFT DN100/PN16 3.2 LR | DN100 - 4" | Lloyd's / 3.2 | On order |
€887.50 |
| RPMS64N16-150LR | BUTTERFLY VALVE TAPPED ALUMINIUM BRONZE NBR BARE SHAFT DN150/PN16 3.2 LR | DN150 - 6" | Lloyd's / 3.2 | On order |
€1,112.50 |
Technical characteristics
| Size | DN100 - 4" |
|---|---|
| Connection | Lug |
| Material | Aluminium bronze |
| Pressure | PN16 |
| Certificate | Lloyd's / 3.2 |
| Thread | Female |
| Seal | NBR |
| Brand | RPM |
